- Airmac DBMX120 Linear Diaphragm Pump
DBMX120
The DBMX120 is the 120 l/min linear diaphragm pump from the Airmac DBMX Series. It offers low noise with stable performance over the long lifespan of the pump. It is sold complete with a robust and sound reducing aluminium housing, integrated inlet filter, rubber feet, outlet port with additional rubber elbow connector and clamps, power cord and EU plug.
› Flow rate of 120 l/mim against 200 mbar
› Low power consumption (119 W)
› Long life linear drive
› Safety switch to protect against diaphragm failure
› Fully serviceable (⇒ service kits)
Return to Linear Diaphragm Pump range.
Available to purchase online via BOX-it (see order information below).
Technical Data
| Flow (at 200 mbar) | 120 l/min |
| Operating Pressure Range | 100 to 250 mbar |
| Operating Flow Range | 155 to 100 l/min |
| Current Consumption (at 180 mbar)) | 1.0 A |
| Power Consumption (at 150 mbar) | 119 W |
| Cable Length | 1.8 m |
| Cable Termination | EU Plug |
| Approval | CE (according to EN60335, electrical household appliances), RoHS |
| Operating Temperature Range | -10 to +40 °C |
| Operating Humidity Range | 20 to 80% RH |
| Inlet | Via Integrated filter (under housing cover as replaceable item) |
| Outlet | 18 mm OD port |
| Weight | 9.2 kg |
Order Information
Part Number: 190120.230 DBMX120 230 V / 50 Hz ⇒
Supplied As Standard
Elbow and clamps (x2)
Accessories
All data is representative for initial selection purposes. It is the responsibility of the user to determine suitability for the intended use.
