- Airmac DT80 Linear Diaphragm Pump
The DT80 is the 80 l/min linear diaphragm pump from the Airmac DT Series. It offers both compact design and extremely low power consumption which significantly reduces operating costs over the long lifespan of the pump. It is sold complete with a robust and sound reducing aluminium housing, integrated inlet filter, rubber feet, outlet port with additional rubber elbow connector and clamps, power cord and EU plug.
› Flow rate of 80 l/mim against 150 mbar
› Extremely low power consumption (58 W)
› Compact design
› Long life linear drive
› Safety switch to protect against diaphragm failure
› Fully serviceable (⇒ service kits)
Return to Linear Diaphragm Pump range.
Available to purchase online via BOX-it (see order information below).
|Flow (at 150 mbar)||80 l/min|
|Operating Pressure Range||100 to 250 mbar|
|Operating Flow Range||90 to 55 l/min|
|Current Consumption (at 150 mbar))||0.34 A|
|Power Consumption (at 150 mbar)||58 W|
|Cable Length||1.8 m|
|Cable Termination||EU Plug|
|Approval||CE (according to EN60335, electrical household appliances), RoHS|
|Operating Temperature Range||-10 to +40 °C|
|Operating Humidity Range||20 to 80% RH|
|Inlet||Via Integrated filter (under housing cover as replaceable item)|
|Outlet||18 mm OD port|
Part Number: 180080.230 DT80 230 V / 50 Hz ⇒
Supplied As Standard
Elbow and clamps (x2)
All data is representative for initial selection purposes. It is the responsibility of the user to determine suitability for the intended use.
