3MD Liquid Diaphragm Pump

€186.39*

Available, shipping in 1 - 2 days

Motor / Voltage
Diaphragm
Part Number: 3232.660

24 V BLDC liquid diaphragm pump.

4 wires:
red = supply (+24 V DC)
black  = GND
green  = speed input (0 to 5V or 0 to 100% PWM)
yellow  = tacho output (1 pulse per revolution)
*can be connected to supply valtage for full speed

Supplied with 2 mounting clip (as shown in photo).

Recommended tubing: 4.8mm ID silicone (see accessories below)

Product information "3MD Liquid Diaphragm Pump"

Flow to 2.5 l/m
Pressure to 1.6 bar
Vacuum to -700 mbar
Suction height (dry) to 4.5 m
