7KD Series

The 7KD series is unique high performance gas diaphragm which is particularly suited for gas / dust monitoring as well as industrial vacuum applications. The pump is fitted with internal damping chambers and resonanting membrane. The dual head arrangement further balances flow.

The use of high performance plastics facilitates use in high temperature applications such as combusion gas analysis. The overall construction is extremely robust.

Vibration mounts are fitted as standard.

This pumps is also available in a quad head arrangement (see 7KQ series).

Return to Miniature Diaphragm Pumps for Air and Gas range.

Brushed DC Motor

Quality brushed motor available in 12 and 24 V.

Available to purchase online via BOX-it (see order information below).

Technical Data

Free flow 32 l/min
Max pressure 600 mbar
Max vacuum -400 mbar
Voltage options 12 / 24 V DC
Power Consumption 36 to 50 W
Elastomers Nitrile
Other wetted parts PPS (Polyphenylene Sulphide)
Configuration Heads connected in parallel
Tube connections Barb for 6 mm to 8 mm ID tube
Max ambient temperature 50°C
Max media temperature 100°C
Weight 1100g







Order Information

Part Number:     7502.012     12 V DC / Nitrile     ⇒ BOX-it
Part Number:     7502.024     24 V DC / Nitrile     ⇒ BOX-it

All data is representative for initial selection purposes. It is the responsibility of the user to determine suitability for the intended use.
